## Background

We will implement active window tracking functionality within an Electron application with native code (Objective-C) on MacOS and bind it to our Electron app via NAPI. What this means is that, we will always notify our app from the native side, whenever a user changes from one window to another. Regardless of how the user changes between windows (e.g: CMD + Tab, clicking from one app to another), by the end of this tutorial, we will be able to get the id of the active window in the Javascript world. So you can use the window id later on to, for example, do some screen recording but that's out of the scope of this tutorial.

<br />

### What will we cover:

1. We'll use [electron-react-boilerplate](https://github.com/electron-react-boilerplate/electron-react-boilerplate) to create an Electron app (if you already have an existing Electron app, feel free to use that as a starting point). At the time of writing, Electron is at `v20.0.2`.
2. We'll write the native code.
   1. Create the necessary files (`activeWindowObserver.h`, `activeWindowObserver.mm`, `nativeWindows.mm`)
   2. Write `activeWindowObserver.h`
   3. Implement `activeWindowObserver.mm`
   4. Implement `nativeWindows.mm`
3. Setup build scripts with `electron-rebuild`.
4. We'll create a Typescript wrapper for our native code.
5. We will call it from our `main` Javascript process and log the results to the console.

### Prerequisites:

- Your app needs `Accessibility` permission, so if you run it from the Terminal, make sure to grant the `Accessibility` permission to the Terminal, and later, once you build it to a standalone app, to your app.

> If you run it from VSCode's Terminal, make sure the permission is given to VSCode as that will be the owner process that spawns the Terminal. Same applies for any other integrated terminal.

- We assume that you're familiar with Typescript and Electron to a certain degree.

<br />
<br />

### 1. Create an Electron boilerplate

```
git clone --depth 1 --branch main https://github.com/electron-react-boilerplate/electron-react-boilerplate.git electron-active-window-tracking

cd electron-active-window-tracking
```

You should have a barebones electron boilerplate and stand inside the root of that folder.

### 2. Writing the native code

#### Install NAPI

We will use `node-addon-api` for binding our ObjectiveC++ code to Node. In this tutorial, we use `v4.3.0`. We'll create the necessary files for the build in a minute, but if you want to read more about setting it up, you can read it [on github](https://github.com/nodejs/node-addon-api/blob/main/doc/setup.md).

```sh
npm i node-addon-api@4.3.0
```

#### Create the folder structure for our native module

We will call our module `native-windows`, and we will create a `macos` folder in it, as we have the possibility to extend it for Windows as well.

```sh
mkdir -p src/native-modules/native-windows/macos
```

#### Setup NAPI

In `src/native-modules/native-windows`, create a file named `binding.gyp` with the below content:

```gyp
{
  "targets": [
    {
      "target_name": "nativeWindows",
      "cflags!": ["-fno-exceptions"],
      "cflags_cc!": ["-fno-exceptions"],
      "include_dirs": ["<!@(node -p \"require('node-addon-api').include\")"],
      "defines": ["NAPI_DISABLE_CPP_EXCEPTIONS"],
      "conditions": [
        [
          "OS==\"mac\"",
          {
            "sources": [
              "<!@(node -p \"require('fs').readdirSync('./macos').map(f=>'macos/'+f).join(' ')\")"
            ],
            "libraries": ["-framework Cocoa"]
          }
        ]
      ]
    }
  ]
}
```

A `.gyp` file is basically a JSON file that is used to generate Makefiles used to compile our `ObjectiveC++` program. It's consumed by `node-gyp`, which is the build tool we'll use. We assume that our app will be built on MacOS. We will need the Cocoa framework, to be able to use MacOS specific APIs. Node-gyp compiles a `.node` file from our `ObjectiveC++` source code, that contains the bindings for our module and that can be imported to a `js` file.

Also add a `package.json` file here, with the below content:

```json
{
  "name": "native-windows",
  "version": "0.1.0",
  "scripts": {
    "install": "node-gyp rebuild"
  },
  "gypfile": true
}
```

This file basically marks that this module is a `C++` module that we'll bind to NodeJS.

#### Create necessary files

In `src/native-modules/native-windows/macos` folder, create a `activeWindowObserver.h`, a `activeWindowObserver.mm`, and a `nativeWindows.mm` file.

The `.h` file is a header file. If you're not familiar with `C++`, consider `.h` files as interfaces, that define what is implemented in the `.mm` file in our case.

The `activeWindowObserver.mm` contains the implementation for what's defined in the `.h` file. The `.mm` extension is specific for `ObjectiveC++`.

The `nativeWindows.mm` file contains the bindings that enable us to use our module from JS.

#### Write `activeWindowObserver.h`

```c++
#pragma once
#include <stdio.h>
#include <string>
#include <Cocoa/Cocoa.h>
#include <napi.h>

void initActiveWindowObserver(Napi::Env env, Napi::Function windowCallback);
void stopActiveWindowObserver(Napi::Env env);

@interface ActiveWindowObserver: NSObject
- (id) init;
- (void) dealloc;
- (void) cleanUp;
- (void) removeWindowObserver;
- (void) receiveAppChangeNotification:(NSNotification *) notification;
- (void) getActiveWindow;

@end
```

#### Implement `activeWindowObserver.mm`

```c++
#import "activeWindowObserver.h"
#include <iostream>

Napi::ThreadSafeFunction activeWindowChangedCallback;
ActiveWindowObserver *windowObserver;

auto napiCallback = [](Napi::Env env, Napi::Function jsCallback, std::string* data) {
    jsCallback.Call({Napi::String::New(env, *data)});

    delete data;
};

void windowChangeCallback(AXObserverRef observer, AXUIElementRef element, CFStringRef notificationName, void *refCon) {
    if (CFStringCompare(notificationName, kAXMainWindowChangedNotification, 0) == kCFCompareEqualTo) {
        NSTimeInterval delayInMSec = 30;
        dispatch_time_t popTime = dispatch_time(DISPATCH_TIME_NOW, (int64_t)(delayInMSec * NSEC_PER_MSEC));
        dispatch_after(popTime, dispatch_get_main_queue(), ^(void){
            NSLog(@"mainWindowChanged");
            [(__bridge ActiveWindowObserver*)(refCon) getActiveWindow];
        });
    }
}

@implementation ActiveWindowObserver {
    NSNumber *processId;
    AXObserverRef observer;
}

- (void) dealloc
{
    [[[NSWorkspace sharedWorkspace] notificationCenter] removeObserver:self];
    [super dealloc];
}

- (id) init
{
    self = [super init];
    if (!self) return nil;

    [[[NSWorkspace sharedWorkspace] notificationCenter] addObserver:self selector:@selector(receiveAppChangeNotification:) name:NSWorkspaceDidActivateApplicationNotification object:nil];

    return self;
}

- (void) receiveAppChangeNotification:(NSNotification *) notification
{
    [self removeWindowObserver];

    int currentAppPid = [NSProcessInfo processInfo].processIdentifier;
    NSDictionary<NSString*, NSRunningApplication*> *userInfo = [notification userInfo];
    NSNumber *selectedProcessId = [userInfo valueForKeyPath:@"NSWorkspaceApplicationKey.processIdentifier"];

    if (processId != nil && selectedProcessId.intValue == currentAppPid) {
        return;
    }

    processId = selectedProcessId;

    [self getActiveWindow];

    AXUIElementRef appElem = AXUIElementCreateApplication(processId.intValue);
    AXError createResult = AXObserverCreate(processId.intValue, windowChangeCallback, &observer);

    if (createResult != kAXErrorSuccess) {
        NSLog(@"Copy or create result failed");
        return;
    }

    AXObserverAddNotification(observer, appElem, kAXMainWindowChangedNotification, (__bridge void *)(self));
    CFRunLoopAddSource([[NSRunLoop currentRunLoop] getCFRunLoop], AXObserverGetRunLoopSource(observer), kCFRunLoopDefaultMode);
    NSLog(@"Observers added");
}

- (void) getActiveWindow
{
    CFArrayRef windowsRef = CGWindowListCopyWindowInfo(kCGWindowListOptionOnScreenOnly, kCGNullWindowID);
    NSArray<NSDictionary*> *windowsArray = (NSArray *)CFBridgingRelease(windowsRef);
    NSPredicate *pIdPredicate = [NSPredicate predicateWithFormat:@"kCGWindowOwnerPID == %@ && kCGWindowLayer == 0", processId];
    NSArray *filteredWindows = [windowsArray filteredArrayUsingPredicate:pIdPredicate];
    NSDictionary *activeWindow = filteredWindows.count > 0 ? filteredWindows.firstObject : Nil;

    if (activeWindow == Nil) {
        return;
    }

    NSLog(@"%@ activeWindow",activeWindow);

    NSNumber *windowId = [activeWindow valueForKey:@"kCGWindowNumber"];
    std::string *result = new std::string([[windowId stringValue] UTF8String]);
    activeWindowChangedCallback.BlockingCall(result, napiCallback);
}

- (void) removeWindowObserver
{
    if (observer != Nil) {
        CFRunLoopRemoveSource([[NSRunLoop currentRunLoop] getCFRunLoop], AXObserverGetRunLoopSource(observer), kCFRunLoopDefaultMode);
        CFRelease(observer);
        observer = Nil;
    }
}

- (void) cleanUp
{
    [[[NSWorkspace sharedWorkspace] notificationCenter] removeObserver:self];
    [self removeWindowObserver];
}
@end

void initActiveWindowObserver(Napi::Env env, Napi::Function windowCallback) {
    activeWindowChangedCallback = Napi::ThreadSafeFunction::New(env, windowCallback, "ActiveWindowChanged", 0, 1);
    windowObserver = [[ActiveWindowObserver alloc] init];
}

void stopActiveWindowObserver(Napi::Env env) {
    [windowObserver cleanUp];
    windowObserver = Nil;
    activeWindowChangedCallback.Abort();
    activeWindowChangedCallback = Nil;
}
```

##### Explanation of the above code:

- `windowChangedCallback` is used to track changes between windows that belong to the same application
  ​
  You might wonder why that 30ms delay is before fetching again the frontmost window. Without delay, we always get the windows in the order of the previous state, so it was always one step behind what actually the user sees. Presumably it is caused by the lack of synchronicity of the APIs that we use, although it is just a guess. However, I filed an issue to Apple about this strange behaviour, as it might be a bug. In case you are interested in the future of this issue, you can track it on the following link: [Apple Forum](https://developer.apple.com/forums/thread/713113)

- `dealloc` is used to remove observers
- `init` we add an observer to the notification center of the shared workspace that let's us listen to changes between applications
- `receiveAppChangeNotification` is the handler itself that's attached in init. In this handler, we define another observer, that subscribes to the window changes that belong to the same application (`windowChangeCallback`).
- `getActiveWindow` is responsible for getting the frontmost window's id
- `removeWindowObserver` detaches the observer
- `cleanUp` removes the window change observer, and the app change observer
- `initActiveWindowObserver` triggers the initialization of an instance of the above class, this is the function that we wrap with NAPI and call from JS
- `stopActiveWindowObserver` triggers the destruction of our instance and removes every listener

#### Implement `nativeWindows.mm`

```c++
#import <Cocoa/Cocoa.h>

#import <stdio.h>
#import <napi.h>
#import "./activeWindowObserver.h"

void StartActiveWindowObserverMethod(const Napi::CallbackInfo& info) {
  Napi::Env env = info.Env();
  initActiveWindowObserver(env, info[0].As<Napi::Function>());
}

void StopActiveWindowObserverMethod(const Napi::CallbackInfo& info) {
  Napi::Env env = info.Env();
  stopActiveWindowObserver(env);
}

Napi::Object NativeWindows(Napi::Env env, Napi::Object exports) {
  exports.Set(Napi::String::New(env, "startActiveWindowObserver"),
              Napi::Function::New(env, StartActiveWindowObserverMethod));
  exports.Set(Napi::String::New(env, "stopActiveWindowObserver"),
              Napi::Function::New(env, StopActiveWindowObserverMethod));
  return exports;
}

NODE_API_MODULE(nativeWindows, NativeWindows)
```

Pretty straightforward, we just wrap the two methods we exposed from our module and make it available from JS.

### 3. Setup build scripts with `electron-rebuild`

```
npm i -D electron-rebuild
```

Add the following lines to our main `package.json` file, that's in the Electron project's root.

```json
{
  "scripts": {
    ...,
    "native-modules:rebuild": "npm run native-modules:clean && npx electron-rebuild -f -m src/native-modules/native-windows",
    "native-modules:rebuild:arm": "npm run native-modules:rebuild -- --arch arm64",
    "native-modules:clean": "rimraf src/native-modules/**/bin && rimraf src/native-modules/**/build"
  }
}
```

If you have no errors in your native code, you should be able to build your module correctly by running `npm run native-modules:rebuild` or `npm run native-modules:rebuild:arm` depending on which platform you want to build for in your root folder.

It should have a similar output to this:
![Successful build of the native module](successful-native-module-build.webp)

### 4. Create a Typescript wrapper for our native code

> Add the below lines to `.eslintrc.js` if you've started from the electron-react-boilerplate

```json
{
  rules: {
    ...,
    'class-methods-use-this': 'off',
    'import/prefer-default-export': 'off',
  }
}
```

Add the following to `src/native-modules/native-windows/index.ts`

```ts
interface Addon {
  startActiveWindowObserver: (callback: (activeWindow: string) => void) => void;
  stopActiveWindowObserver: () => void;
}

// eslint-disable-next-line
const addon: Addon = require('./build/Release/nativeWindows.node');

class NativeWindows {
  /**
   * Subscribes to active window changes
   */
  public startActiveWindowObserver(callback: (window: string | null) => void) {
    addon.startActiveWindowObserver(callback);
  }

  public stopActiveWindowObserver() {
    addon.stopActiveWindowObserver();
  }
}

export const nativeWindows = new NativeWindows();
```

We export a `nativeWindows` variable that's our instantiated class with correcty typing, that imports our native code as `addon` from the compiled code.

### 5. Call our module from `main.ts`

Inside `main.ts` add the following import:

```ts
import { nativeWindows } from '../native-modules/native-windows';
```

Somewhere below, after the app is ready, add the following code to test what we've done:

```ts
nativeWindows.startActiveWindowObserver((windowId) => {
  console.log('native window id', windowId);
});
```

After that, start the app with `npm start`.

You should see logs like:

![Successful output of native module](successful-output.webp)

🎉This should be it, you're done. You should be able to track active windows on MacOS by this point.🎉

The complete code is available on our Github on the following link:
https://github.com/scriptide-tech/blog-tracking-active-window-macos-objective-c-electron
